Trade on the DEX

Find pools and prices, check balances, estimate and execute a swap, and add or remove liquidity on the BitBadges DEX from the CLI, TypeScript, or raw messages.

Set SIGNER to the wallet address authorized to sign the transaction, matching its explicit creator or sender. Browser deployment requires this binding even when reading a saved transaction.

At the end you have swapped one asset for another on the BitBadges chain and know how to join or exit a liquidity pool. The DEX is the x/gamm module (a generalized automated market maker with balancer pools); the messages, queries, and fee rules are in x/gamm. Routing can also cross IBC chains such as Osmosis through Skip:Go; the estimate endpoint is documented in Swaps.

Prerequisites:

The bb CLI with a BitBadges API key configured (bb settings set apiKey "$BITBADGES_API_KEY"), or the bitbadges npm package. Create a key at bitbadges.io/developer.
A wallet with ubadge for fees. --browser signs through the BitBadges /sign page with Keplr or MetaMask.

Amounts are raw base units everywhere: 1000000 is 1 BADGE at 6 decimals.

1. Find Pools and Prices

bash

# Every pool, sorted by liquidity (also: volume, dailyVolume, weeklyVolume,
# monthlyVolume, allTimeVolume, lastLiquidityUpdate, lastVolumeUpdate)
bb pools list --sort-by liquidity --sort-order desc

# One pool: assets, total liquidity, total shares, volume buckets
bb pools show 1

# Pools that contain an asset, by symbol or canonical denom
bb pools by-denom BADGE
bb pools by-denom ibc/E1116484B327AEE59CDC3DA73D319834781A13DB2A7DFC1F38A30CD45ABF58B8

# Pools for a pair, order-insensitive
bb pools by-assets ubadge USDC

# Several pools at once
bb pools batch 1 2 3

Prices come from the BitBadges API's asset records. Symbols resolve through asset-pair search:

bash

bb price ubadge                     # native BADGE
bb price BADGE                      # same, symbol resolved
bb price ubadge,ibc/E1116484B327AEE59CDC3DA73D319834781A13DB2A7DFC1F38A30CD45ABF58B8     # batch via CSV
bb price BADGE USDC

Asset-pair analytics and the asset browser:

bash

bb pairs list
bb pairs search USDC
bb pairs by-denoms ubadge ibc/E1116484B327AEE59CDC3DA73D319834781A13DB2A7DFC1F38A30CD45ABF58B8
bb pairs top-gainers          # last 24h
bb pairs top-losers
bb pairs highest-volume       # sorted by 24h volume
bb pairs weekly-top-gainers   # last 7d
bb pairs weekly-top-losers
bb pairs price-sorted

bb assets list --sort-by volume24h --limit 20
bb assets show BADGE
bb assets browse              # top gainers, losers, and highest volume, as on bitbadges.io
bb assets price ubadge BADGE  # same lookup as bb price

bb pairs and bb pools were bb swap asset-pairs and bb swap pools in CLI v1; the old spellings are deprecated aliases kept for one release. Cross-chain assets and chains come from Skip:Go:

bash

bb swap assets --include-svm --include-cw20
bb swap chains

In TypeScript the same data is api.getAllPools, getPoolInfoById, getPoolInfosByDenom, getPoolInfosByAssets, and getAssetPairs; see Swaps.

Ask your agent. With the MCP builder tools installed, paste one of these:

text

Using the liquidity-pools skill, create a balancer pool of BADGE and the wrapped token of collection 1 with a 0.3% swap fee, and give me the review link.

text

Look up the current price of BADGE in USDC and the pools that hold both.

2. Check Balances

Three asset-scoped views:

bash

# Cosmos native and IBC fungibles, straight from the chain LCD (no API key)
bb balances ics20 bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d
bb balances ics20 bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d --denom ubadge

# BitBadges-standard tokens (multi token ID, time-ranged shape)
bb balances bitbadges bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d --collection 1

# Swap-consolidated view: Skip:Go plus verified BitBadges assets, including
# wrapped assets (badgeslp:, badges:) with numeric amounts. Use this for swap UIs.
bb balances assets bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d
bb balances assets 0x0bc63cfe31d5218eb414b142c799e20964a54a1a --chain 1
bb balances assets bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d --all-chains

bb balances ics20 accepts --lcd <url> for any Cosmos chain and --page-key for pagination. A 0x address passed to bb balances bitbadges is converted to bb1 with a notice on stderr.

For several chains in one call, pass a chain-to-addresses map. Responses for BitBadges chains include server-side wrappable amounts for verified badge denoms:

bash

bb swap balances '{"bitbadges-1": ["bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d"], "1": [{"address": "0x0bc63cfe31d5218eb414b142c799e20964a54a1a", "denoms": ["ethereum-native"]}]}'
bb swap balances @chains.json

3. Convert Amounts and Set Slippage

Decimals come from the BitBadges coins registry when you pass --denom; pass --decimals to override.

bash

bb amount to-raw 1.5 --denom BADGE              # 1500000
bb amount to-raw 1.5 --decimals 6 --round ROUND_UP
bb amount to-display 1500000 --denom ubadge     # 1.5
bb amount to-display 1500000 --denom ubadge --precision 2

# Minimum acceptable output for a 0.5% tolerance
bb amount min-amount --expected 5000000 --slippage-pct 0.5
bb amount min-amount --expected 5000000 --slippage-bps 50

# Realized slippage after the fact (positive = received less than expected)
bb amount slippage --expected 5000000 --actual 4975000

bb amount max-wrappable, wrap-preview, and unwrap-preview convert through a collection's wrapper path; see Wrap to an IBC Denom.

4. Estimate the Swap

bash

# 1 BADGE -> USDC on the BitBadges chain, 1% slippage (default)
bb swap estimate ubadge uusdc 1000000

# Native pools only, no Skip:Go rerouting (both chains must be bitbadges-*)
bb swap estimate ubadge uusdc 1000000 --local-only --slippage 0.5

# Cross-chain: addresses are required for every chain on the route
bb swap estimate uatom ubadge 1000000 --source-chain cosmoshub-4 \
  --addresses '{"bitbadges-1":"bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d","cosmoshub-4":"cosmos1p0rrel3365scadq5k9pv0x0zp9j22js6wwxdnu"}'

ts

import { BigIntify, BitBadgesAPI } from 'bitbadges';

const api = new BitBadgesAPI({ convertFunction: BigIntify, apiKey: process.env.BITBADGES_API_KEY });

const response = await api.estimateSwap({
  tokenIn: 'amount:1000000,denom:ubadge',
  tokenInChainId: 'bitbadges-1',
  tokenOutDenom: 'uusdc',
  tokenOutChainId: 'bitbadges-1',
  chainIdsToAddresses: { 'bitbadges-1': 'bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d' },
  slippageTolerancePercent: 1
});

console.log(response.estimate.tokenOutAmount);
console.log(response.estimate.skipGoMsgs);
// Use the msgs to get user signatures and execute the swap

Read these fields before you execute:

Field	Meaning
`tokenOutAmount`, `tokenInAmount`	Estimated output and the input you passed
`skipGoMsgs`	Messages to sign: a multi-chain message for Cosmos chains or an EVM transaction for EVM chains
`assetPath`	Each hop: `denom`, `chainId`, and `how` (`genesis`, `swap`, `transfer`)
`doesSwap`	`true` if a swap happens; `false` if the route is only a transfer
`lowLiquidityWarning`	Pool liquidity is low; execution may differ from the estimate
`complianceNotPassedWarning`, `complianceErrorMessage`	Compliance checks failed; the BitBadges pool swap is likely to fail
`estimatedTime`	Seconds to completion, when available
`fallbackAsset`	Asset delivered if the swap is not possible

chainIdsToAddresses accepts bitbadges-1 (bech32 bb address) and 1 (EVM 0x address); other chain addresses are derived from these. chainIdsToAffiliates adds fee recipients per chain in basis points. forcefulRecheckCompliance bypasses the 5 minute compliance cache. The full payload and response types are in Swaps.

Skip:Go compatibility is partial. skipGoMsgs follow the Skip API message format, but Skip's own API, engines, explorers, and client may not support BitBadges routing; only Cosmos swaps are recommended (no ETH or SOL routes yet).

5. Execute the Swap

A BitBadges-only route (one native swap, no Skip:Go rerouting, no EVM transaction, no IBC-transfer leg, no WETH redirect) signs and broadcasts from the CLI:

bash

# Sign + broadcast in one step through the /sign page
bb swap estimate ubadge uusdc 1000000 --addresses "{\"bitbadges-1\":\"$SIGNER\"}" --execute --browser --expected-address "$SIGNER"

# Also seed the swap activity row after broadcast
bb swap estimate ubadge uusdc 1000000 --addresses "{\"bitbadges-1\":\"$SIGNER\"}" --execute --browser --expected-address "$SIGNER" --track

# Or emit the signable message and pipe it into bb deploy
bb swap estimate ubadge uusdc 1000000 --addresses "{\"bitbadges-1\":\"$SIGNER\"}" | bb swap execute | bb deploy --browser --expected-address "$SIGNER" --msg-stdin

# From a saved estimate
bb swap execute @estimate.json --browser --expected-address "$SIGNER"

Without a deploy flag, bb swap execute prints the signable message to stdout so scripting keeps working.
--force broadcasts a route flagged for compliance or low liquidity; otherwise it is refused.
Cross-chain, EVM, and multi-hop estimates are returned but not executed. The execute path throws a not-implemented error with no partial execution. Sign the estimate in your wallet through the /sign page, broadcast the first transaction, then track it:

bash

bb swap track E5B4C3A6E5B1F3B9F0F4C1F2B7A6D5C4E3F2A1B0C9D8E7F6A5B4C3D2E1F0A9B8 --chain-id bitbadges-1 --token-in 1000000ubadge
bb swap status E5B4C3A6E5B1F3B9F0F4C1F2B7A6D5C4E3F2A1B0C9D8E7F6A5B4C3D2E1F0A9B8 --chain-id bitbadges-1
bb swap activities

To submit the on-chain message yourself, build a MsgSwapExactAmountIn and deploy it. token_out_min_amount is the slippage guard from step 3; routes lists one pool per hop; affiliates take basis points of the output (10 = 0.1%).

bash

bb deploy '{
  "typeUrl": "/gamm.v1beta1.MsgSwapExactAmountIn",
  "value": {
    "sender": "bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d",
    "routes": [{ "poolId": "1", "tokenOutDenom": "uusdc" }],
    "tokenIn": { "denom": "ubadge", "amount": "1000000" },
    "tokenOutMinAmount": "4975000",
    "affiliates": []
  }
}' --browser --expected-address bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d

Proto and JSON field names for every gamm message are in x/gamm Messages. Signing options (keyring, browser, external signer via bb gen-tx-payload) are in Deploy commands.

6. Provide Liquidity

Join a pool with tokens in the pool's current proportions. You receive LP shares, and token_in_maxs caps what can be taken from you:

bash

bb deploy '{
  "typeUrl": "/gamm.v1beta1.MsgJoinPool",
  "value": {
    "sender": "bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d",
    "poolId": "1",
    "shareOutAmount": "1000000",
    "tokenInMaxs": [
      { "denom": "ubadge", "amount": "1000000" },
      { "denom": "uusdc", "amount": "5000000" }
    ]
  }
}' --browser --expected-address bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d

Exit by burning shares. token_out_mins is the floor for each asset returned; the pool decides the proportions, and some pools charge an exit fee:

bash

bb deploy '{
  "typeUrl": "/gamm.v1beta1.MsgExitPool",
  "value": {
    "sender": "bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d",
    "poolId": "1",
    "shareInAmount": "100000",
    "tokenOutMins": [
      { "denom": "ubadge", "amount": "90000" },
      { "denom": "uusdc", "amount": "450000" }
    ]
  }
}' --browser --expected-address bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d

Create a balancer pool with initial liquidity, weights, and fees. The pool ID is in the transaction response. Wrapped BitBadges tokens trade under badgeslp:<collectionId>:<denom> denoms:

bash

bb deploy '{
  "typeUrl": "/gamm.poolmodels.balancer.MsgCreateBalancerPool",
  "value": {
    "sender": "bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d",
    "poolParams": { "swapFee": "0.003", "exitFee": "0.000" },
    "poolAssets": [
      { "token": { "denom": "ubadge", "amount": "1000000" }, "weight": "50" },
      { "token": { "denom": "badgeslp:1:utoken", "amount": "5000000" }, "weight": "50" }
    ]
  }
}' --browser --expected-address bb1p0rrel3365scadq5k9pv0x0zp9j22js6dnw70d

Check the position afterwards with bb pools show <pool-id> and bb balances ics20 <address> (LP shares are a bank denom).

Next Steps

Swaps for the estimate payload and response reference.
Swap commands for every bb swap, pools, pairs, price, assets, balances, and amount flag.
Wrap to an IBC Denom to make a collection's tokens tradable in a pool.
